Product Details
1-1/4" V10 Alloy Sub-Assembly with small sub-links 39,700 lbs WLL
SKU: P-8452410
1-1/4" V10 Alloy Sub-Assembly with small sub-links 39,700 lbs WLL You can use this to make quad-legged slings.
| Availability: | In Stock |
| Ships From: | Dallas, TX |
| Color: | Blue |
| Chain Grade: | Grade 100 |
| Chain Link Diameter: | 3/8 inch |
Full Description
• V10 master links feature technical specifications that outperform the standards available on the market. Such achievement is made possible by our integrated manufacturing process that begins with the processing of the raw material and ends with the issuing of the finished product test certificate. The steel bars are bended and processed and the master links are tested.
• V10 master link diameters range from 1/2" (13mm) up to 2-1/4” (60mm), meeting various lifting needs.
• Safety factor 4:1
SKU
8452410-1
Dim A
1.30
Manufacturer Part No.
D32L22
Trade Size (Inches)
1-1/4
Trade Size mm
32
Matching G100 Chain Size (In.) 3-4 Legs
1/2
Lbs. Per Ea.
14.5
Dim B
4.33
Dim C
7.87
Dim A1
0.91
Dim B1
1.97
Dim C1
4.53
Working Load Limit (Lbs.)
39700
