Product Details
1" V10 Peerless Alloy Oblong Master Link 26,000 lb WLL (8451400 alt 8851400)
| Availability: | In Stock |
| Ships From: | Dallas, TX |
| Color: | Blue |
| Chain Grade: | Grade 100 |
| Chain Link Diameter: | 1/2 inch |
Full Description
The 1" Oblong Master Link, made by Peerless, is a high-strength Grade 100 component designed for demanding lifting and rigging applications. With an impressive working load limit of 26,400 lbs at a 60° angle, this master link ensures reliable performance under heavy loads. Its durable blue paint finish adds a layer of protection against wear and corrosion, making it a dependable choice for tough jobs.
Part#8451400 alterative 8851400
Trade Size: 1" (26mm)
Matching G100 Chain Size 1 leg: 5/8"
Matching G100 Chain Size 2 legs: 1/2"
Material Diameter: 1.06"
WLL: 8451400: 26,400lbs
WLL:8851400: 26,000lbs
Finish: Blue Powder Coat
V10™ Oblong Master Links
V10™ Oblong Master Links are a vital core component of any chain sling. Optimally designed for use with crane hooks, The V10™ Oblong Master Link is available in sizes ranging from 1/2" (13mm) to 2-3/8” (60mm) in diameter, for both welded and mechanical slings. This versatile, forged, and welded link allows for overhead lifting applications and is engineered to meet or exceed OSHA, Government, NACM, and ASTM specs. All V10™ products are accompanied with a product test certificate.
Each forged master link is marked with a traceability and heat code, A10 designation 100, manufacturer’s mark, and angle indicators at 45 degrees from vertical.
STANDARDS
- Meets or exceeds ASTM A952, NACM, & OSHA 910 Standards
- Safety factor 4:1
- Fatigue Tested at 1.5 times the WLL for 20,000 cycles
- Proof Tested at twice the WLL
HEAT TREATMENT
- Quenched and tempered before proof testing
ORIGIN
- Made in Italy or Germany
LINK TYPE
- Master Link
APPLICATION
- For overhead lifting
- Suited for use with wire rope, chain, and slings
MATERIAL
- Premium Fine Grain Alloy Steel
