Product Details
1/2" G100 Peerless V10 Self-Locking Hook 15,000 lb WLL
One (1) 1/2" Grade 100 Clevis Self Locking Hook
Peerless Brand V10 Hook
15,000 lbs safe WLL (working load limit)
Peerless V10 hooks are easily recognizable by the deep blue color
| Availability: | In Stock |
| Ships From: | Dallas, TX |
| Color: | Blue |
| Chain WLL Grade 100: | 8,800 lbs |
| Chain Grade: | Grade 100 |
| Chain Hook Style: | Clevis Safety Latch |
| Chain Link Diameter: | 3/8 inch |
Full Description
V10™ CLEVIS SELF-LOCKING HOOKS
The V10™ Clevis Self-locking Hook features a positive locking latch that ensures safety and security during lifts and while under load. Quenched and tempered before proof testing, the V10™ Clevis Self-locking Hook meets or exceeds OSHA, Government, NACM, and ASTM specs. All V10™ products are accompanied with a product test certificate.
- ChainSize:1/2" (13mm)
- Dim A: 0.591"
- Dim D: 2.717"
- Dim G: 1.358"
- Dim H: 1.575"
- Dim O: 2.028"
- Dim P x L: 0.63" x 1.46"
- Dim R: 7.067"
- Weight per Ea: 6.9Lbs
- WLL: 15,000Lbs
GRADE: 100
FINISH: Blue Powder Coat Finish
STANDARDS: Meets or exceeds ASTM A952, NACM, & OSHA 910 Standards
Fatigue Tested at 1.5 times the WLL for 20,000 cycles
Proof Tested at twice the WLL
Safety factor 4:1
ATTACHMENT: Clevis
HEAT TREATMENT: Quenched and tempered before proof testing
ORIGIN: Made in Italy
HOOK TYPE: Self-locking Hook
APPLICATION: Overhead Lifting
MATERIAL: Premium Fine Grain Alloy Steel
• V10 fittings’ technical features outperform current market standards. Such accomplishment is made possible by our integrated manufacturing process that begins with the raw material and ends with the issuing of the test certificate of the finished product
• The production cycle begins with the hot forming process and ends with the final test
• Safety factor 4:1
• Compliant with the main international standards (EN, ASTM, AS).
